Frozen Soap Bubbles: The Science of the Snow-Globe Effect

Share this story
FacebookWhatsApp
More
PinterestTelegramXEmail

Blow a soap bubble on a bitterly cold day, set it down on ice, and within seconds feathery crystals begin to swirl across its skin until the whole sphere turns to frost. The video Frozen Bubbles, uploaded to YouTube in March 2013 by the channel then known as SimonSaysBaka and now listed as Mycelium, captured the kind of scene that later sent a team of engineers into the laboratory.

Soap bubble held near a window in a frame from the Frozen Bubbles video
A soap bubble at the start of the freeze. Credit: Mycelium; channel formerly credited as SimonSaysBaka.

How a soap bubble freezes

A soap bubble is a shell of water and soap only a tiny fraction of a millimetre thick, wrapped around a pocket of air. When it rests on a frozen surface, the base touches the cold first and that is where freezing begins. A freeze front then creeps up the curved film towards the top.

Animation of ice forming across a transparent soap bubble – Mycelium (SimonSaysBaka)
Frost spreads up the bubble from its base. Credit: Mycelium; channel formerly credited as SimonSaysBaka.

Freezing water releases heat, known as latent heat. As the front advances, it warms the liquid just above it, so the bottom of the bubble ends up warmer than the top. In Virginia Tech's experiments the top of the bubble was at about −20 °C while the frozen base had warmed to around −6 °C, a difference of roughly 14 degrees.

The snow-globe effect explained

In 2019 a team led by Jonathan Boreyko, a mechanical engineer at Virginia Tech, published the first detailed study of freezing soap bubbles in Nature Communications. The project started when the researchers saw a YouTube video of a bubble freezing with ice crystals floating around it, and found that nobody had studied how soap films freeze.

Their explanation is called the Marangoni effect. Surface tension changes with temperature, so the temperature gradient across the bubble drives a flow in the liquid film from the warmer bottom towards the colder top. That flow tears tiny ice crystals off the freeze front and carries them upward. Each crystal keeps growing as it swirls through the film, so hundreds of them freeze the bubble at almost the same time. Physicists call this the snow-globe effect.

Ice crystals spreading over a frozen soap bubble, animation from Frozen Bubbles
Close animation of pale ice patterns spreading across a bubble – Mycelium (SimonSaysBaka)
Ice crystals swirl and multiply across the film. Credit: Mycelium; channel formerly credited as SimonSaysBaka.

What the experiments showed

The details of the setup make all the difference:

  • On a dry frozen plate in the lab, bubbles froze from the bottom up only to a certain point and then stopped. The team built a model that predicts where freezing stops from the bubble's size and the air temperature.
  • In a freezer at about −20 °C, with the bubble resting on ice, the snow-globe effect appeared. The bubble filled with floating crystals and froze much faster.

Boreyko pointed out that the swirling flow creates many extra freeze fronts, so the speed of freezing depends on how many fronts work together. The Caltech physicist Kenneth Libbrecht, an expert on snow crystals, summed up the key finding: freezing creates liquid flows that in turn speed up freezing.

The research may one day help scientists understand freezing in biological tissue, an area where large samples such as whole organs are still damaged when they are frozen and thawed.

Frozen soap bubble covered in frost patterns, animation from Frozen Bubbles

Watch the Frozen Bubbles video

Watch the base of each bubble first, where the frost begins, then follow the pale crystals as they drift up and multiply. To try it yourself, wait for a calm, very cold day, use a straw or bubble wand, and land the bubble gently on snow or ice, as in the Virginia Tech freezer tests. The colder the air, the better your chances of seeing the full snow-globe swirl.

For another view of small-scale ice growth, explore our ice-crystal feature, and for frozen forms shaped by winter weather, see frost patterns on cars.

Sources
